Also available in S350 for even better span.
To ensure that the correct product is used in every (country) situation, we will be pleased to help you with your design of spans, deflections, supports, and wind, snow and temperature loads. For more information you can contact the Product Services department: +31-(0)30 68 79 790.
Or you can use SAB-Static, the free designprogramm for steeldeck, single sheet cladding profiles and liner trays.'
Specifications
| Steel | |
| mm | kg/m2 |
| 0,75 | 11,78 |
| 0,88 | 13,82 |
| 1,00 | 15,70 |
| 1,13 | 17,74 |
| 1,25 | 19,63 |
| 1,50 | 23,55 |
- Maximum length: 27,5 m
- Minimum length: 0,6 m
- Available in S320 and S350
- Available with perfo (just P3 L-S)
- Available with SAB Rain Water Solution
- Production NL
