The Etihad Museum in Dubai, designed by Moriyama Teshima Architects, is a striking architectural landmark that embodies the history and identity of the United Arab Emirates. Inspired by a manuscript, the building's fluid form symbolizes the signing of the UAE’s constitution in 1971. The museum provides an immersive journey through the nation’s history, featuring permanent and temporary exhibitions that celebrate the UAE’s past, present, and future. The design integrates cultural storytelling with cutting-edge architectural innovation, making it a defining feature of Dubai’s civic landscape.

Situated on Dubai’s Waterfront, the Etihad Museum honours the United Arab Emirates’ (UAE) conception story. Comprised of a parabolic shaped Pavilion structure and subterranean Museum, the Etihad Museum is framed around the historic Union House where the nation’s Constitution was signed in 1971. Recognizable by its unique scroll-like form that mimics the parchment paper of the Constitution, the entry features bronze metal text citing the nation’s founding philosophy. Seven rows of embossed bronze columns mimic the form and angle of pens in motion, referencing the act of writing which formalized the seven emirates in this unification.

photo_credit Victor Romero
Victor Romero
photo_credit Victor Romero
Victor Romero

The pavilion features a stark contrast in its material palette – pristine white marble floors extend throughout the space and form the Amphitheatre steps that allow for an informal gathering space for school groups and seminars to be held. While heavily textured, ribbed black marble stone envelops the building’s core and connects visitors to the upper level mezzanine that houses a café and flexible exhibition space.

photo_credit Victor Romero
Victor Romero

A carefully crafted experience takes the Pavilion visitors below grade via a grand staircase and ramp whose forms echo the brilliant and flowing calligraphic lines of Arabic script. Once they have descended, visitors re-encounter the familiar circular form of Union House through a newly instated foundation wall clad in dune-like carved stone. This familiar element becomes a central organizing feature in the visitor flow through the museum, giving the visitor a constant point of reference as they navigate the massive open permanent gallery and supporting spaces that circumscribe it. The flow of movement is further highlighted by the billowing white ceiling planes that take form from the patterns of prevailing wind patterns rippling on the desert sands and is accentuated by the carved wood columns and luster of the bronze forms that highlight the warmth of this lower level.

photo_credit Felix Loechner
Felix Loechner

Comprised mostly of permanent and temporary galleries, theatre, event spaces, and archival facilities, the planning of this underground museum relied on the absence of natural light in spaces that would not benefit from their exposure. The integration of two spacious sunken courtyards and four large skylights that connect to the plaza above allow for key functional areas: the classrooms, research library, administration offices, prayer rooms, and café were strategically clustered around these natural light sources to optimize their use.

The nature of the Museum’s programming as an immersive learning environment demanded an ease and flow of movement to maximize the visitor’s experience. Multimedia screens are interspersed throughout the space and feature educational content to cultivate the site as an active historic and cultural campus.

photo_credit Victor Romero
Victor Romero

Beneath the Etihad Pavilion's simple continuous double-curved skin is a highly sophisticated envelope and sub-substructure assembly. In order to achieve the large cantilevers of the curving shell that give the impression of a floating piece of paper, innovations in the steel super structure and cladding assemblies had to be made. Both the large Eastern entrance overhang and angled structural columns created a major structural eccentricity that required the primary glazed façade to become a part of the structure and act in shear. The single element structural glass columns for this façade also make it the world’s first sloping glass fin façade.

photo_credit Victor Romero
Victor Romero

Clad entirely in double-curved GFRP (Glass Fiber Reinforced Polymer), the Pavilion shell employed sophisticated parametric design strategies to precisely inform four core teams involved in the technical development of the complex envelope. These tools played a pivotal role in the design of the Pavilion’s panelization. After an exhaustive form search, a diamond subdivision was selected to emphasize the curvature of the folding paper form, with further subdivisions of the grid creating a secondary layer of micro texture and whirling movements across the windswept façade. During construction, a calligraphic dual coloured gradient frit was substituted with cutting edge glass coatings to maintain high levels of façade transparency whilst maintaining solar gain and glare control targets

photo_credit Felix Loechner
Felix Loechner

Project credits

Product spec sheet

Roofing

Project data

Project Year
2016
Category
Museums

Etihad Museum shines on thanks to UltraPly TPO

Etihad Museum shines on thanks to UltraPly TPO
Applied products
View all applied products

More from the Manufacturer:

To ensure the long-term performance of the Etihad Museum’s unique roof design, Elevate’s UltraPly TPO system was selected for its exceptional durability and energy efficiency. Covering approximately 6,000 m², the white UltraPly TPO membrane was mechanically attached over mineral wool, providing superior waterproofing while withstanding Dubai’s extreme heat and UV exposure. Thanks to its high reflectivity, the UltraPly TPO system helps reduce heat absorption, contributing to the museum’s overall energy efficiency and sustainability.

Caption

The Etihad Museum in Dubai opened its doors in January 2017. It houses permanent and temporary exhibitions on the history of the United Arab Emirates (UAE) and its people. The building was designed in the shape of a manuscript, recalling the signing of the UAE’s constitution in 1971.

Holcim Solutions and Products

Elevate’s UltraPly TPO system was chosen to ensure the watertightness of the Etihad Museum’s roof. About 6,000 m² of white UltraPly TPO membrane were mechanically attached over mineral wool.

The UltraPly TPO roofing system provides outstanding performance in the dry and high-temperature climate of Dubai thanks to its excellent UV and ozone resistance. In addition, its outstanding reflectivity contributes to improving the energy efficiency of buildings: the top layer reflects the sunlight before it is absorbed and converted into heat radiation.

photo_credit Holcim Solutions and Products
Holcim Solutions and Products
