Thanks to its greater installation depth and wall thickness, the Jansen Economy 60 system is particularly suitable for large, heavy duty single and double doors and for applications requiring higher levels of security.
Materials / surface finish
Uncoated steel or strip-galvanised steel, suitable for powder coating or stove-enamelling
Element types
-Single and double doors, with or without side panels and transom windows
-Sheet metal clad doors with or without cut-outs for glazing
-Anti-finger-trap doors
-Pivot door and folding wall available as a special design
Equipment
-Steel hinges are available for welding or screw fixing
-Integrated door closers, concealed hinges and follower hooks
-Multipoint locks (motorised also available)
-Designer glazing beads
-Emergency locks and panic push-bars
Special technical features
-Installation depth 60 mm
-Special geometries (semi-circular tops)
-Jansen Economy 60 anti-finger-trap door
Test certificates
CE marking in accordance with product standard EN 14351-1
-Tightness against heavy rain up to class 5A
-Air permeability up to class 4
-Resistance to wind load up to class C5
-Sound insulation up to Rw 45 dB
-Burglar resistance in accordance with EN 1627 up to RC (WK) 3
-Bullet resistance FB 4-6 S/NS
-Emergency exit door in accordance with EN 1125 / EN 179
-Mechanical strength class 4
-Conditions for approval fulfilled
-Conditions for supporting safety devices fulfilled
