• Open aperture design with fully luminous interior.
  • No horizontal lenses or diffusers.
  • Precision machined clear anodized, extruded aluminum.
  • Five endcap styles, preinstalled for perfect fit and finish.
  • Up to 15ft o.c. spacing, delivering 40 fc at less than 0.4 W/ft.sq.
Product Name
Profile
Designer
Fluxwerx
Manufacturer
Fluxwerx
Manufactured
Canada
Interior Lighting
LED, Pendants and Linear lighting
Light source
LED
Lighting type
Direct-indirect
Colour
Grey range
Black range
Silver range
White range

BIM & CAD Files

A linear LED pendant luminaire with unique hollow aperture, Profile combines minimalist design and architectural-grade materials with superior optical and energy performance, delivering precise batwing distribution, exceptional functionality and energy efficiency.

The luminaire’s finely detailed exposed architecture delivers unparalleled clarity right through the fixture.



Perfect for retail, commercial, institutional and healthcare environments, Profile combines modern form with advanced technology, engineering ingenuity and an obsessive attention to detail, enabling inspired environments that are luminous and comfortable.



Specifications:



Combining architectural design and small aperture size, Profile is a linear LED pendant luminaire that features second-generation anidolic extraction optics with low brightness and high-performance continuous lenses featuring superior efficacy.



Manufactured in 4′ and 8′ nominal sections and with no electrical connections at fixture joints required, Profile can be installed as an independent pendant or as a continuous lighting system with virtually seamless runs. Its anodized architectural grade extruded aluminum components are precision machined for seamless fit. Available in four finish options (clear anodized, plus white, silver and black powdercoat), Profile can be specified in any custom RAL powdercoat finish. Its agnostic drivers can be integrated with any sensor, lighting control, or building energy management system.



Profile’s low brightness, continuous lenses emit light from both interior planes of the luminaire, efficiently and precisely directed to create a batwing distribution in both the hemispheres. A choice of various output and distribution options allows Profile to be used as a discrete and minimal lighting solution in various environments and conditions. In addition, Profile is also available with an independent up-down lighting control option that provides fully dimmable or switchable independent control of the upper and lower hemispherical distributions.



The luminaire’s color accuracy is within a two-step MacAdam ellipse and is available in multiple correlated color temperatures (CCT) with high CRI values. Profile is offered as standard with lumen maintenance of L70 at 200,000 hours; its life mid-flux LED systems are optically and thermally designed to maintain 90% of initial lumen output for more than 60,000 operating hours (L90 > 60,000 h), as per TM21 guidelines.



Profile offers multiple options for high-efficiency integral multivolt drivers that are factory prewired for all circuits; flexible driver orientations and simple installation methods that accommodate most new construction or retrofit ceiling conditions. Agnostic driver design enables simple integration with any sensor, lighting control or building energy management system.



Product benefits

  • Open aperture design with fully luminous interior.
  • No horizontal lenses or diffusers.
  • Precision machined clear anodized, extruded aluminum.
  • Five endcap styles, preinstalled for perfect fit and finish.
  • Up to 15ft o.c. spacing, delivering 40 fc at less than 0.4 W/ft.sq.
  • Direct and direct/indirect general area lighting versions.
  • Also available in vertical surface illumination (VSI)
  • Strategic LED selection, binning and board design.
  • Available in 3000K, 3500K or 4000K with SDCM < 2 and CRI > 80.
  • Third party tested and backed by a 5-year warranty.
